Anchormax Cray Pot Crab Pot Winch Hauler 12 volt & foot switch + Circuit Breaker

Anchormax Cray Pot Crab Pot Winch Hauler 12 volt & foot switch + Circuit Breaker

$749.00

  • Maxwell Anchormax Cray Pot  or Crab Pot Hauler winch with deck switch included
  • An extremely versatile vertical capstan or general purpose electric winch for use as an anchor, pot hauler or davit winch.
  • The ANCHORMAX? has an extremely high power to weight ratio.
  • The compact, fully sealed gearbox is driven by a vertically mounted, permanent magnet motor. Intrusion below decks is minimised making the design ideal for boats from 5m (16ft) to 10m (32ft). Fitting to the boat is simplicity itself as no dismantling of the winch is required.
  • The ANCHORMAX? gear housings are marine-grade alloy and the drum is stainless steel. It is supplied as a single direction (clockwise) unit, complete with deck switch, fastenings, template & fitting instructions.
  • Max Line Pull Lift 386KG
  • Power 500 watts
  • Voltage 12 or 24 Volt
  • Speed @ normal working load 24 metres/min (80 amps with 100kg load)
  • Weight of unit 8Kg
  • 80 amp Circuit Breaker Isolator is recommended. The Anchormax is not recommended for haul halyards or to haul chain. It comes with a 3 year limited warranty.
  • P100790 Circuit Breaker /Isolator Panel Included, 80 Amp.
