Maxwell Anchormax Crayfish Hauler Crab Pot Winch 12 volt with foot switch

Maxwell Anchormax Crayfish Hauler Crab Pot Winch 12 volt with foot switch

$907.00 $999.90

FREE DELIVERY AUSTRALIA WIDE- SAME DAY DISPATCH


An extremely versatile vertical capstan or general purpose electric winch for use as an anchor, pot hauler or davit winch.

Maxwell Anchormax Crayfish Hauler or Crab Pot Hauler winch with deck switch included.

  • The ANCHORMAX has an extremely high power to weight ratio.
  • The compact, fully sealed gearbox is driven by a vertically mounted, permanent magnet motor. Intrusion below decks is minimised making the design ideal for boats from 5m (16ft) to 10m (32ft). Fitting to the boat is simplicity itself as no dismantling of the winch is required.
  • The ANCHORMAX gear housings are marine-grade alloy and the drum is stainless steel. It is supplied as a single direction (clockwise) unit, complete with deck switch, fastenings, template and fitting instructions.
  • Maxwell Anchormax Crayfish Hauler .

Specifications:

  • Maximum Pull/Lift: 330kg (740 lbs)
    • Speed @ nominal working load: 24m/min
    • 80amps with 100kg/220lb load: 76 per min
  • Voltage: 12V
  • Power: 500W
  • Weight: 8kg (17.6lbs)
  • Maximum Boat Length: 10m (33')
  • Maximum Boat Weight: 4 tonnes
  • Cable Sizes:
  • Up to 5m run use: 15mm2 cable
  • 5m to 10m use: 25mm2 cable
  •  We Currently Have Stock For immediate dispatch.

PART NO: 100461

GET IT QUICK!   SAME OR NEXT BUSINESS DAY DISPATCH

ONLY JUST BACK IN STOCK, LIMITED NUMBERS.
